SYLSMART DCS LR SSC
Item No:
V960016
SylSmart DCS-LR is a Bluetooth-controlled, long-range, SylSmart Standalone-enabled, DALI controller. SylSmart-DCS-LR does not have its own power supply. Instead, it is powered directly from a DALI bus.
SylSmart Standalone-DCS-LR can be used with a DALI sensor for presence detection or daylight harvesting, or it can be used for controlling DALI drivers that have an integrated DALI bus power supply.
Technical Assets
Dimensions (mm)
Photometrics
Product name
SYLSMART DCS LR SSC
Technology
Electronic Device
Type of accessory
Control
Built in presence detector
NONE
Operating temperature range (°C)
-25°C...+55°C
Warranty
5 years
Primary Supply/Product voltage - min (V)
9.5
Primary Supply/Product voltage - max (V)
22.5
Dimmable
Yes
Dimming method
DALI-2
Nominal Frequency (Hz)
DC
Housing colour
White
Nominal Product Length (mm)
40.4
Nominal Product Width (mm)
36.3
Nominal Product Height (mm)
14
Weight (kg)
0.015
Packaging single length / height (cm)
4.1
Packaging single width (cm)
3.7
Packaging single depth (cm)
1.4
Units per outer package
1
Packaging outer length / height (cm)
41.0
Packaging outer width (cm)
37.0
Packaging outer depth (cm)
14.0
Optimal operating condition (°C)
-25-55
