SYLMIRROR LED SLIM IP44 NW
Item No:
0043213
.png)
LED mirror/cabinet light with 8W total power consumption, 560 lumen, 110° beam angle, IP44, IK03, CRI 80, 4000K colour temperature, 400 mm length, 2 year warranty. Slim shape. The luminaire is controlled via the wall switch for on/off operation
Technical Assets
Dimensions (mm)
Photometrics
Product name
SYLMIRROR LED SLIM IP44 NW
Technology
LED
Cap/Base
N/A
Housing
Aluminium
Mount
Wall surface mounted
Built in presence detector
NONE
Fixture rating
Enclosed
General application
Residential & Consumer
Operating temperature range (°C)
-10°C...+45°C
Performance ambient temperature Tq (°C)
25
Virtual assistant compatibility
N/A
ETIM Class
EC002892
E-number FI
4170555
E-number SE
7505161
Warranty
2 years
Fixture luminous flux (lm)
560
Luminaire efficacy (lm/W)
70
LOR (%)
100
Correlated colour temperature (k)
4000
Light colour
Neutral White
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Distribution type
Symmetric
Photobiological Risk Group
RG0
Emergency type
Total power consumption (W)
8
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Lamp power factor
0.5
THD (at 230 V, 50 Hz, full load, at 100% dimming level) ≤ xx.x %
100
Electrical protection
Class II
Control gear required
No
Control gear type
LED driver constant current
Dimmable
No
Dimming method
N/A
Drive current (mA)
60
Inrush Current (A)
2
Inrush Duration (µs)
50
Energy Efficiency Class (A->G) of contained light source
F
Nominal Frequency (Hz)
50/60Hz
Max. products per 10A C Breaker
100
Max. products per 16A C Breaker
200
Max. products per 16A B Breaker
200
Connectable conductor cross section - Max (mm²)
1.5
Lifespan L70 B50
25000
Housing colour
Chrome
IP rating
IP44
IK rating
IK03
Diffuser finish
Opal
Diffuser material
PC Polycarbonate
Nominal Product Length (mm)
400
Nominal Product Width (mm)
120
Nominal Product Height (mm)
45
Weight (kg)
0.206
Product EAN number
5410288432137
Packaging single length / height (cm)
41.0
Packaging single width (cm)
13.2
Packaging single depth (cm)
5.5
DUN14 (inner)
15410288432134
Units per outer package
6
Packaging outer length / height (cm)
43.0
Packaging outer width (cm)
42.0
Packaging outer depth (cm)
13.5
Glow Wire Test (°C)
650
Optimal operating condition (°C)
-10-45
