F6W/T5/33-640
Item No:
0000013
This product is no longer available
.
Technical Assets
Dimensions (mm)
Photometrics
Product name
F6W/T5/33-640
Technology
Fluorescent
Lamp shape
Tubular shape
Cap/Base
G5
Lamp finish
Frosted/Coated
Fixture rating
Open
General application
Education, Hospitality, Logistics & Industry, Museums & Galleries, Office, Retail, Residential & Consumer
ETIM Class
EC000108
E-number FI
4942321
E-number SE
8356708
E-number Norway
3822407
Useful luminous flux (Φuse)
280
Luminous flux (Rated) (lm)
280
Rated lamp efficacy 100h 50Hz at 35°C (lm/W)
48
Ambient temperature for maximum luminous flux (°C)
25
Correlated colour temperature (k)
4000
Light colour
Cool White
Colour Code
640
CRI (Ra)
64
Colour Variation Initial (SDCM)
SDCM5
Adjustable chromaticity
N
Photobiological Risk Group
Not applicable
Rated lumen maint. factor (%) at 2000 h 50Hz
0.88
Rated lumen maint. factor (%) at 4000 h 50Hz
0.82
Rated lumen maint. factor (%) at 6000 h 50Hz
0.78
Rated lumen maint. factor (%) at 8000 h 50Hz
0.75
Power consumption (W)
5.8
Wattage (W)
6.00
Supply current (A)
0.160
Primary Supply/Product voltage - min (V)
36.0
Primary Supply/Product voltage - max (V)
48.0
Control gear required
Yes
Dimmable
Yes
Drive current (mA)
160
Lamp Energy Label (class)
G
kWh per 1000 hours burning time
7
Average life (Nominal) (h)
10000
Average life (Rated) (h)
10000
Rated survival factor (%) at 2000 h 50Hz
1.00
Rated survival factor (%) at 4000 h 50Hz
0.99
Rated survival factor (%) at 6000 h 50Hz
0.96
Rated survival factor (%) at 8000 h 50Hz
0.83
Nominal Product Length (mm)
225.0
Nominal Product Diameter (mm)
16
Max. Length base to base (mm) - A
212.1
Length base to pin Min-Max (mm) - B
216.8-219.2
Max. Lamp Length (mm) - C/L
226.3
Max. Lamp Diameter (mm) - D
17.0
Weight (kg)
0.022
Product EAN number
5410288000138
Packaging single length / height (cm)
22.7
Packaging single width (cm)
1.9
Packaging single depth (cm)
1.9
DUN14 (inner)
15410288000135
DUN14 (outer)
25410288000132
Units per outer package
25
Packaging outer length / height (cm)
24.0
Packaging outer width (cm)
10.0
Packaging outer depth (cm)
10.0
Lamp mercury content (mg)
2.30
Breakage cleaning instructions
Applicable
Recommendation for disposal at end of life
Applicable
Special purpose lamp
No
Suitable for household illumination
Yes
